KYORITSU 2433/2433R

AC A
(50/60Hz) 40/400mA/400A
|±1%rdg±5dgt (40/400mA)
|±1%rdg±5dgt (0 - 350A)
|±2%rdg (350.1 - 399.9A) AC A
(WIDE) 40/400mA/400A
|±1%rdg±5dgt [50/60Hz],
|±2.5%rdg±10dgt [20Hz - 1kHz] (40/400mA)
|±1%rdg±5dgt [50/60Hz],
|±2.5%rdg±10dgt [40Hz - 1kHz] (0 - 350A)
|±2%rdg [50/60Hz],
|±5%rdg [40Hz - 1kHz] (350.1 - 399.9A) Frequency Response 20Hz - 1kHz (40Hz - 1kHz:400A) Maximum
Circuit Voltage 600V AC/DC (between line/neutral)
300V AC/DC (against earth) Conductor Size Ø40mm max. Safety Standard IEC 61010-1 CAT III 300V Pollution Degree 2
IEC 61010-2-032 Effect of External
Stray Magnetic Field 10mA AC approx. in proximity to a 15mm-dia
conductor carrying 100A AC Withstand Voltage 3700V AC for 1 minute Response Time Approx. 2 seconds Power Source Two R03 or equivalent (DC1.5V) batteries Dimensions 185(L) × 81(W) × 32(D)mm Weight 270g approx. Accessories 9052 (Carrying Case)
R03 (1.5V) × 2
Instruction Manual Optional 8008 (Multi-Tran)*
