Display and user interface
Graphic display
LC display, backlit white.
Size: 128 x 64 Pixel, corresponds to 59 x 31 mm = 2.32" x 1.22"
Display can be turned in steps of 90
°
.
Ambient temperatures below -25
°
C / -13
°
F, may affect the readability of the display.
Operating elements
4 optical keys for operator control of the signal converter without opening the
housing.
Infrared interface for reading and writing al
l parameters with IR interface (option)
without opening the housing.
Remote control
PACTware
®
(incl. Device Type Manager (DTM))
HART
®
Hand Held Communicator from Emerson Process
AMS
®
from Emerson Process
PDM
®
from Siemens
All DTMs and drivers are available free of charge from the manufacturer's website.
Display functions
Display functions
Display functions
Display functions
Operating menu
Setting the parameters usin
g 2 measured value pages, 1 status page, 1 graphics
page (measured values and gr
aphics are freely adjustable)
Language display texts (as
language package)
Standard: English, French, German, Dutch,
Portuguese, Swedish,
Spanish, Italian
Eastern Europe: English, Sl
ovenian, Czech, Hungarian
Northern Europe: Engl
ish, Danish, Polish
China: English, Chinese
Russia: English, Russian
Units
Metric, British and US units selectable as required from lists for volume / mass flow
and counting, flow velocity, electrica
l conductivity, temperature, pressure
Measuring accuracy
Reference conditions
Medium: water
Temperature: 20
°
C / 68
°
F
Pressure: 1 bar / 14.5 psi
Inlet run:
≥
5 DN
Maximum measuring error
±
0.15% of the measured value
±
1 mm/s, depending on the measuring sensor
For detailed information and accura
cy curves, see chapter "Accuracy".
Repeatability
±
0.06% to OIML R117; not valid for WATERFLUX 3000
