Product Description
Easy to use, calibrate and configure, the BIOGAS 5000 enables you to collect consistent data for improved analysis and accurate reporting, whilst helping to check the digester process is running efficiently.
Benefits
- No need for self-certification of anemometer: certified analyser validates results
- Guarantees quality analysis and reporting: supports your analysis by providing consistent and reliable collection of data
- Boasts Geotech’s ‘best in class’ infra-red bench technology
- Adheres to strict PPC compliance
- Geotech configures the BIOGAS 5000 specifically for your company’s unique specification
- Supports the efficiency of your digestion process: provides you with insight so you can change gas levels for optimum performance
- Provides peace of mind that your desulpherisation process is working correctly by measuring pre and post desulphurisation levels
- Enables you to monitor how efficiently your engine is working and its life expectancy by monitoring sulphur levels
Specification
- Robust design: Reliable, high quality design fit for the most hazardous AD sites
- Gases measured: CH4 (0-100%); CO2 (0-100%); O2 (0-25%)
- Optional extra gases: H2 (0-1000ppm); NH3 (0-1000ppm); H2S (0-50, 200, 500, 1,000, 5,000 or 10,000ppm)
- Multilingual menu: English , French, German, Spanish, Portuguese, Italian, Chinese
- 3 years free warranty
- Accreditation: ATEX; MCERTS; CSA; UKAS Calibration (ISO17025)
- Additional extras: Pitot tube for flow measurement; ATEX anemometer and ATEX temperature probe for flow measurement
- Optional Gas Analyser Manager Software (GAM) for ID set up and data download
- New firmware updates available – released May 2016
